Mobile pallet inverters with side press

The mobile pallet inverters with side press can change loads of up to 800 kg, without height limitations. The changing from one pallet to another is done without rotating the load.

The inverter has two presses with rubber surfaces, which help the load to be stable and sustain it during transfer. The height to which it can rise the load is 300 mm.

Is recommended for applications where the load has regular shapes, but the height of the stacks and the loading place varies.

The mobile pallet inverters with side press is available both in standard model and in WB model (for pallets with atypical dimensions or which have no spaces between the skids).

For more information, please consult the technical details presented in Documentation.

Technical specifications

Cod produs: N.A.

Capacity: 800 kg

N. 2 lateral presses: 800x1194 mm

Pallet maximum dimension: 1200x800 mm, 1200x1000 mm, 1200x1200 mm

Base width: 1300 mm (interior space)

Maximum lifting height: 1050 mm

Control of lateral forks: independent

Traction: electrical

Charger: 24V - 110 Ah

Battery charger: 24V - 25 Ah type WB
