Forklift attachments for bulk box handling

For these forklift attachments for bulk box handling there are two main models: one that catches the container from the lateral sides, and one that catches it from under the base, but also grips it from the upper edge close to the operator, fixing this way the container so it can be rotated for unloading.

This forklift attachment is often used to handle the products and components which require support from multiple sides during unloading.

The arms of the forklift attachment have a supplementary rubber layer which protects the container during handling, and prevents it from slipping.

The forklift attachments for bulk box handling are available in many configurations, with lengths and widths according to the client’s applications.

This product is suited especially for those in recycling industry, where the bulk products are stored in containers with skids.

The forklift attachments for bulk box handling is compatible with the containers with feet, less expensive than the ones with skids, where the pressure is distributed proportionally on the lateral walls, leading to a longer service life for these containers.

By using this forklift attachment, the savings can be doubled both by using less expensive containers and for a much longer time.

Technical specifications

Capacity2045 kg / 600 mm
Minimum hook height (A)between 305 mm and 990 mm (depending on the model)
Maximum hook height (B)between 762 mm and 1549 mm (depending on the model)
Container capacity (box / basket / barrel)between 330-610 and 1016-1397 (depending on the model)
Forklift attachment class (ISO 2328)2 or 3 (depending on the model)
Minimum arms aperture (C)432 mm
Maximum arms aperture (D)940 mm
Weightbetween 557 mm and 595 mm (depending on the model)
Forklift attachment thickness (ET)between 272 mm or 302 mm (depending on the model)
Gravity center/ horizontal (HCG)between 196 mm and 224 mm (depending on the model)
Gravity center/ vertical (VCG)between 257 mm and 335 mm (depending on the model)
Min/ max forklift height (OAH)between 800/1145 mm and 1029/1613 mm (depending on the model)
